Night Vision Wireless Color Weatherproof Security Camera NTSC
Night Vision Wireless Color Weatherproof Security Camera NTSC
This camera is weatherproof with a sturdy alloy shell for outdoor use. It has built-in infra-Red LED 12x.
Enter your e-mail address to be notified when product is in stock
Notify Me!
Product Description

NTSC Night Vision Wireless Weatherproof Security CCTV Camera

You can also Check out the youtube link below:


Image pickup: 1/3

TV system: PAL/CCIR NTSC/EIA 1.2 GHz

Definition: 380 TV Lines

Transmission distance without blocking: 50m-100m

Easy installation

Viewable on your monitor and television

Color day video

Black and white night video



6 Month Warranty


    Electric power:  DC 8V
    Output power:  50mW - 200mW

    Video input: 1.5VP-P (Max.)

    Power consumption current:  150mA

    Audio input:  2VP-P (Max.)

    Effective range (no obstacles): 50m - 150m

   Operating Temperature:  -20 to 60 degrees Celsius

   Operating Humidity:  85% RH


CMOS Nightvision Camera (12x IR LED)
   Image Sensor: 1/3 inch CMOS

   CMOS Total Pixels:  628x582

   Sync System:  Internal

   Minimum Illumination: 0Lux @F1.2 (IR ON)

  Resolution: 380 TV Line

  Lens focus: 6.0mm

  Effective picture element: PAL (628x582)

  NTSC (510x492)

  Scan frequency:  PAL/CCIR: 50Hz   NTSC/EIA: 60Hz

  Output standard: CCIR/EIA (PAL/NTSC)

  White Balance Mode: AWB (Zero color rolling)

  Gain Control: AGC

  S/N Ratio:  48dB(Min)/60dB(TYP)(AGC OFF)

  Electronic Shutter:  1/50 - 1/10,000sec

  Gamma Correction: 0.45

  Illumination Distance: 7-10 meters






This NTSC camera has high quality color CMOS sensor for crisp clear images. When there is visible light the camera will display images in full color and the night vision will kick in when visibility is low. The camera is not very large and can be placed almost anywhere it is very discreet. Conveniently viewable on your computer or television, this camera can record to any device with a video input and recording capabilities.

This camera is weatherproof with a sturdy alloy shell for outdoor use. It has built-in infra-Red LED (12x): For color pictures during the day and black and white at night. It has a long operational range of up to about 300 ft. line-of-sight or 98ft through obstructions (walls/ceilings). A universal swivel base is included for your convenience for easy mounting to walls or ceilings.


UPC CODE: 859456002324

Reviews (1)
Name : Bryant
Location :
Title :
Review : Great use for my small company that I own to surveillance suspicious activity.

Questions (11)
What electrical cords come with it? D.c. charger ?

It comes with the power cable for both the camera and receiver.

Does the camera work on batteries? Where I won't have to run wires or have an electrician put a plug outside.

Yes, it comes with a 9v battery adapter that connects to the camera.

1.-Does the camera has long cable to connect to powere (if not , you sell it? How long? ) 2.- do you sell a device for record?

we sell adapters not the long cable. We do not sell a recorder.

Do you have a outdoor camara that you could watch one hundred an twenty miles away that’s wireless and you don’t have to have internet


Once motion activated how long does it record? Will it automatically turn off when motion stops? How long will the 8 volt battery last before needing to change it?

the battery will last long but it depends on the amount of usage. Keep it mind it is a transmitter not a recorder.

Do you have to have internet to use this camara


How many days does this unit hold video recording and as long as I have a smart tv this unit will adapt to it?And I'm assuming there's a monitoring service or not?

it is a transmitter not a recorder. You must connect it to your memory device. Also, it depends on the smart TV whether it will adapt. Most users plug it in to a tape recorder.

Does this receiver and camera come with all the cords ? Is it a wireless camera as well ? Will it turn on and record when it catches motion detection. Because I’m looking to put a SD or SSD card in it. But I want to make sure I can record off detected motion etc. what’s the max SD card it can hold ?

Dear Customer, This camera is mont based off of motion detection and cannot read an SD card. Thanks

Will this camera interface with our aux input on our factory installed nav/back up system. There is an aux input for video.

Dear Customer, Thank you for your question. Please kindly refer to the product specs on our website for information regarding the aux input.

I want to know do I need internet for this camera to work and can I use my phone to monitor it and I can only use one device per camera

Dear Customer, No you cannot connect to your phone. Thank you

I do construction and I would like to put cameras so I can wash my people working can also connect three extra cameras on the inside of the properties and use my phone Galaxy so I can wash them working but the important question is do I need to have internet on the house or not

Dear Customer, You will not be able to connect the extra cameras in this situation Thank you
