NTSC Night Vision Wireless Weatherproof Security CCTV Camera
Features:
Image pickup: 1/3
TV system: PAL/CCIR NTSC/EIA 1.2 GHz
Definition: 380 TV Lines
Transmission distance without blocking: 50m-100m
Easy installation
Viewable on your monitor and television
Color day video
Black and white night video
BUY WITH CONFIDENCE
6 Month Warranty
Specifications:
Transmission:
Electric power: DC 8V
Output power: 50mW - 200mW
Video input: 1.5VP-P (Max.)
Power consumption current: 150mA
Audio input: 2VP-P (Max.)
Effective range (no obstacles): 50m - 150m
Operating Temperature: -20 to 60 degrees Celsius
Operating Humidity: 85% RH
CMOS Nightvision Camera (12x IR LED)
Image Sensor: 1/3 inch CMOS
CMOS Total Pixels: 628x582
Sync System: Internal
Minimum Illumination: 0Lux @F1.2 (IR ON)
Resolution: 380 TV Line
Lens focus: 6.0mm
Effective picture element: PAL (628x582)
NTSC (510x492)
Scan frequency: PAL/CCIR: 50Hz NTSC/EIA: 60Hz
Output standard: CCIR/EIA (PAL/NTSC)
White Balance Mode: AWB (Zero color rolling)
Gain Control: AGC
S/N Ratio: 48dB(Min)/60dB(TYP)(AGC OFF)
Electronic Shutter: 1/50 - 1/10,000sec
Gamma Correction: 0.45
Illumination Distance: 7-10 meters
Description:
This NTSC camera has high quality color CMOS sensor for crisp clear images. When there is visible light the camera will display images in full color and the night vision will kick in when visibility is low. The camera is not very large and can be placed almost anywhere it is very discreet. Conveniently viewable on your computer or television, this camera can record to any device with a video input and recording capabilities.
This camera is weatherproof with a sturdy alloy shell for outdoor use. It has built-in infra-Red LED (12x): For color pictures during the day and black and white at night. It has a long operational range of up to about 300 ft. line-of-sight or 98ft through obstructions (walls/ceilings). A universal swivel base is included for your convenience for easy mounting to walls or ceilings.
UPC CODE: 859456002324
SKU: ATL2jNV1CM
How can the camera be wireless if it needs to be plugged into an outlet? I assume the transmitter in the house needs to be plugged into a outlet?It can either be plugged into an outlet or a 9V battery.
Can I put the camera on my Quadcopter and still fly around within a hundred feet will it receive the pictures?Yes, you should be able to.
Do you have to use a battery? Or can you plug the camera and receiver into ac?Hi,
You can plug into Ac.
What electrical cords come with it? D.c. charger ?It comes with the power cable for both the camera and receiver.
Does the camera work on batteries? Where I won't have to run wires or have an electrician put a plug outside.Yes, it comes with a 9v battery adapter that connects to the camera.
1.-Does the camera has long cable to connect to powere (if not , you sell it? How long? )
2.- do you sell a device for record? we sell adapters not the long cable. We do not sell a recorder.
Do you have a outdoor camara that you could watch one hundred an twenty miles away that’s wireless and you don’t have to have internet no.
Once motion activated how long does it record? Will it automatically turn off when motion stops? How long will the 8 volt battery last before needing to change it? the battery will last long but it depends on the amount of usage. Keep it mind it is a transmitter not a recorder.
Do you have to have internet to use this camarano
How many days does this unit hold video recording and as long as I have a smart tv this unit will adapt to it?And I'm assuming there's a monitoring service or not?it is a transmitter not a recorder. You must connect it to your memory device. Also, it depends on the smart TV whether it will adapt. Most users plug it in to a tape recorder.
Does this receiver and camera come with all the cords ? Is it a wireless camera as well ? Will it turn on and record when it catches motion detection. Because I’m looking to put a SD or SSD card in it. But I want to make sure I can record off detected motion etc. what’s the max SD card it can hold ?Dear Customer,
This camera is mont based off of motion detection and cannot read an SD card.
Thanks
Will this camera interface with our aux input on our factory installed nav/back up system. There is an aux input for video.Dear Customer,
Thank you for your question. Please kindly refer to the product specs on our website for information regarding the aux input.
I want to know do I need internet for this camera to work and can I use my phone to monitor it and I can only use one device per cameraDear Customer,
No you cannot connect to your phone.
Thank you
I do construction and I would like to put cameras so I can wash my people working can also connect three extra cameras on the inside of the properties and use my phone Galaxy so I can wash them working but the important question is do I need to have internet on the house or notDear Customer,
You will not be able to connect the extra cameras in this situation
Thank you
